Everbilt Submersible Sump Pump Instructions: A Comprehensive Guide

by

The Everbilt submersible sump pump is a reliable solution for basement water management. This guide provides detailed instructions for installation, troubleshooting, and maintenance. Proper installation ensures optimal performance, while regular maintenance extends the pump’s lifespan. The Everbilt pump requires a specific sump pit size, correct discharge pipe setup, and appropriate power supply. Following these instructions will help homeowners effectively manage water levels and prevent basement flooding.

What Tools and Materials Are Needed for Installation?

Before beginning the installation process, gather the following tools and materials:

  • Drill with a 3/16 drill bit
  • Bucket for old pump and water removal
  • Primer and PVC cement
  • Hacksaw
  • PTFE pipe thread sealant tape
  • Wire ties
  • Check valve
  • Discharge pipe (1-1/2\” or 1-1/4\” FNPT)
  • Adapter (1-1/2\” MNPT x 1-1/4\” FNPT)

Having these items on hand will ensure a smooth installation process.

How to Prepare the Sump Pit?

everbilt submersible sump pump instructions

Proper sump pit preparation is crucial for the Everbilt submersible sump pump’s effectiveness. Follow these steps:

  1. Ensure minimum pit dimensions:
  2. Vertical switch models: 10 inches (254 mm) diameter, 14 inches (356 mm) depth

  3. Tethered float switch models: 14 inches (356 mm) diameter, 18 inches (457 mm) depth

  4. Use appropriate materials:

  5. Construct the pit from tile, concrete, steel, or plastic

  6. Remove all debris and small stones

  7. Clean the pit thoroughly before installation

A well-prepared sump pit provides a stable foundation for your pump and ensures proper operation.

What Are the Steps for Installing the Everbilt Submersible Sump Pump?

Follow these steps to install your Everbilt submersible sump pump:

  1. Position the pump:
  2. Place it in the pit with maximum clearance for the switch

  3. Avoid installing on clay, earth, or sand surfaces

  4. Connect the discharge pipe:

  5. Use rigid plastic pipe
  6. Apply PTFE tape to threads
  7. Screw pipe into pump hand-tight plus 1-1/2 turns

  8. Use appropriate adapter for 1-1/2\” or 1-1/4\” pipe

  9. Install check valve:

  10. Place in vertical discharge pipe

  11. Ensure flow direction is away from pump

  12. Connect power:

  13. Plug into 115V GFCI outlet

  14. Use a minimum 15 amp individual branch circuit

  15. Perform operational check:

  16. Fill sump with water
  17. Observe one complete cycle
  18. Ensure pump is stable and float moves freely

How to Troubleshoot Common Everbilt Sump Pump Issues?

When facing problems with your Everbilt sump pump, consider these common issues and solutions:

  1. Pump won’t start or run:
  2. Check for blown fuse or tripped breaker
  3. Ensure plug is secure and clean
  4. Allow pump to cool if overheated

  5. Test float switch functionality

  6. Pump overheating:

  7. Verify discharge pipe size (minimum 1-1/4\” diameter)

  8. Check for pipe restrictions or blockages

  9. Pump running dry:

  10. Ensure sufficient water in sump pit
  11. Check float switch positioning
Problem Possible Cause Solution
No power Blown fuse/tripped breaker Replace fuse/reset breaker
Overheating Undersized discharge pipe Use correct pipe size
Running dry Low water level Adjust float switch

What Maintenance Is Required for the Everbilt Submersible Sump Pump?

Regular maintenance ensures long-term reliability of your Everbilt sump pump:

  1. Periodic inspections:
  2. Check for debris in pump and pit
  3. Ensure inlet screen is clear

  4. Inspect discharge pipe for kinks or blockages

  5. Cleaning routine:

  6. Remove debris from pump and pit

  7. Clean around shaft and under impeller if necessary

  8. Check valve maintenance:

  9. Verify proper operation

  10. Ensure correct installation direction

  11. Power cord and connections:

  12. Inspect for wear or corrosion
  13. Secure cord with wire ties

Implement these maintenance tasks regularly to prevent issues and extend pump life.

What Are the Specific Requirements for Everbilt Sump Pump Setup?

Understanding the specific requirements ensures optimal performance:

  1. Power specifications:
  2. 115V, 60 Hz operation

  3. Minimum 15 amp individual branch circuit

  4. Discharge pipe requirements:

  5. Use 1-1/2\” FNPT or 1-1/4\” FNPT (with adapter)

  6. Maintain minimum 1-1/4\” diameter throughout

  7. Sump pit dimensions:

  8. Vertical switch models: 10\” diameter, 14\” depth minimum

  9. Tethered switch models: 14\” diameter, 18\” depth minimum

  10. Operating conditions:

  11. Liquid temperature range: 32°F to 95°F (0°C to 35°C)

Adhering to these specifications ensures your Everbilt submersible sump pump operates efficiently and safely.

How to Ensure Proper Power Supply for the Everbilt Sump Pump?

Correct power supply is crucial for pump operation:

  1. Voltage requirements:
  2. Use 115V power source

  3. Ensure GFCI protection on outlet

  4. Circuit specifications:

  5. Dedicate a minimum 15 amp branch circuit

  6. Avoid sharing circuit with other high-draw appliances

  7. Cord management:

  8. Secure power cord to discharge pipe

  9. Keep connections dry and elevated

  10. Regular inspections:

  11. Check for cord damage or wear
  12. Ensure plug prongs are clean and secure

Proper power supply management prevents electrical issues and ensures consistent pump operation.

By following these Everbilt submersible sump pump instructions, you can ensure proper installation, troubleshooting, and maintenance of your pump system. Regular attention to these details will help prevent basement flooding and extend the life of your pump.
