The Big Dog Computer Controlled AC/DC Battery Backup Sump Pump System is a high-capacity, dual-power sump pump designed for reliable basement flood protection. With a pumping capacity of 3,500 gallons per hour at 0 feet of lift and 2,200 GPH at 10 feet, this 1/3 HP system offers both AC and DC power options. It features advanced computer-controlled monitoring, dual float switches, and compatibility with Wi-Fi modules for remote notifications.
What Are the Key Specifications of the Big Dog Sump Pump System?
The Big Dog Computer Controlled AC/DC Battery Backup Sump Pump System boasts impressive specifications:
- Pump Capacity: 3,500 GPH at 0 feet lift, 2,200 GPH at 10 feet lift
- Horsepower: 1/3 HP (0.3300 HP)
- Maximum Head Height: 15 feet (7 PSI)
- Voltage: 120 Volt AC / 12 Volt DC
- Running Amps: 10 amps
- Starting Amps: 12 amps
- Discharge Port Size: 1.5 inches
- Weight: 30 pounds (pump only), 150 pounds (complete kit with batteries)
- Warranty: 2 years
These specifications make the Big Dog system a robust solution for residential and light commercial applications.
How Does the Computer-Controlled Monitoring System Work?
The Big Dog sump pump system incorporates advanced computer-controlled monitoring features:
- Power Condition Monitoring: Continuously checks AC and DC power status
- Battery Level Tracking: Keeps tabs on battery charge and health
- Pump Activity Surveillance: Monitors pump operation and performance
- Weekly Self-Test: Automatically conducts a weekly check to detect maintenance needs or potential issues
This intelligent monitoring system ensures the pump is always ready to perform when needed, reducing the risk of unexpected failures.
What Are the Unique Features of the Dual Float Switch?
The dual float switch in the Big Dog system offers several advantages:
- Micro-Reed Technology: Requires only 1/4″ movement to activate the pump
- Independent Mounting: Provides redundancy for enhanced protection
- Precise Activation: Ensures the backup pump starts before the primary pump stops
- Customizable Placement: Can be adjusted to optimize pump cycling and efficiency
This innovative float switch design significantly improves the system’s reliability and responsiveness to water level changes.
How User-Friendly Is the Interface?
The Big Dog sump pump system features a user-friendly interface designed for easy monitoring and maintenance:
| Feature | Function |
|---|---|
| Indicator Lights | Display battery strength and system status |
| Alarm System | Sounds alerts for various issues |
| Warning Lights | Visual cues for maintenance needs |
| USB Port | Allows connection to Wi-Fi module for remote notifications |
The system provides alerts for:
– Low battery fluid level
– Discharged or defective battery
– AC power interruption
– Pump failure
– Reverse battery connection
Additionally, the USB port enables connection to the Watchdog / Pro Series Wi-Fi Module, allowing users to receive notifications via text, email, or the Basement Watchdog App.
What Are the Battery Backup Capabilities?
While the Big Dog system does not include batteries, it is designed to work with specific battery models:
- Compatible Battery: Basement Watchdog 7.5 Hour Standby Deep Cycle Battery (model 30HDC140S)
- Battery Configuration: Can use two batteries in parallel for extended runtime
- Charger Specifications: 20-amp charger for quick battery recharging
- Charging Efficiency: Charger automatically shuts off when battery is full to prolong battery life
The actual runtime depends on the battery used and water inflow rate. For example, with a Basement Watchdog 6 Hour Battery, the system can provide several hours of continuous pumping.
How to Install the Big Dog Sump Pump System?
Follow these steps to install the Big Dog Computer Controlled AC/DC Battery Backup Sump Pump System:
- Prepare the Sump Pit:
-
Clean the pit and ensure it’s large enough for the pump and float switch
-
Install the Pump:
- Place the pump in the pit, ensuring it’s level and secure
-
Connect the discharge pipe and ensure proper venting
-
Mount the Dual Float Switch:
- Attach the switch to the discharge pipe
-
Adjust its height for optimal activation
-
Connect Power and Battery:
- Connect the power cord to a GFCI-protected circuit if necessary
-
Hook up the batteries, ensuring correct polarity
-
Test the System:
- Run a self-test to verify proper functioning
- Check indicator lights and alarms
What Are Common Installation Challenges and Solutions?
When installing the Big Dog sump pump system, be aware of these potential challenges:
-
Proper Venting: Ensure the discharge pipe is correctly vented to prevent backpressure.
-
GFCI Compatibility: If using a GFCI-protected circuit, verify that the pump doesn’t trip the GFCI.
-
Optimal Placement: Position the pump and float switch to maximize efficiency and minimize clogging risks.
-
Battery Maintenance: Regularly check battery fluid levels and connections to ensure reliable backup power.
-
Discharge Line Freezing: In cold climates, take measures to prevent the discharge line from freezing.
By addressing these challenges proactively, you can ensure optimal performance and longevity of your Big Dog sump pump system.
Conclusion
The Big Dog Computer Controlled AC/DC Battery Backup Sump Pump System offers a robust, intelligent solution for basement flood protection. With its high pumping capacity, advanced monitoring features, and user-friendly interface, it provides peace of mind for homeowners in flood-prone areas. While installation requires careful attention to detail, the system’s reliability and performance make it a worthy investment for those seeking top-tier water damage prevention.
